LoRaWAN Smart Button

The ZW-ST801 SOS distress terminal is a product of LPWAN (Low Power Wide Area Network). Based on LoRaTM spread spectrum modulation technology, terminals can communicate over ultra long distances. Manually press the red button to immediately trigger an alarm signal to the monitoring platform, making it easier for monitoring personnel to quickly take rescue measures. Built in high-capacity battery, no wiring required, simple construction, and cost reduction.

Product detail

The ZW-ST801 SOS distress terminal is a product of LPWAN (Low Power Wide Area Network).

Based on LoRaTM spread spectrum modulation technology, terminals can communicate over ultra long distances. Manually press the red button to immediately trigger an alarm signal to the monitoring platform, making it easier for monitoring personnel to quickly take rescue measures. Built in high-capacity battery, no wiring required, simple construction, and cost reduction.

This product is widely used in the M2M industry in the IoT industry chain, such as schools, hospitals, banks, gas stations, residential areas, stations, computer rooms, public toilets, and other application scenarios.

<a href=https://www.zonewu.com/en/LoRaWAN-Sensor.html target='_blank'>LoRa</a> Smart Button2.jpg

LoRa Smart Button3.jpg

LoRa Smart Button4.jpg

Specifications

Wireless Transmission
Communication Protocol	LoRaWAN,LoRa TDMA Networking
Frequency	CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923-1&2&3&4
Tx Power	20dBm (915) / 16dBm (868) / 17dBm (470)
Mode	OTAA/ABP Class A
Interface
Button	1 × External Button
LED Indicator	1 × Status
Buzzer	Support
Operation
Configuration	NFC Configuration via Mobile App
Physical Characteristics
Power Supply	ER14505 Li-SOCl2 4000 mAh battery
Battery Life	≧ 1 years
Operating Temperature	-30°C to 70°C
Dimensions	86x86x26 mm
Installation	On the flat surfaces with 3M tapes
